> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8 MP (3840 ×2160)@25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in multi-core light, the max. IR distance is 50 m and the max. warm light distance is 50 m
> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human)
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 G Micro SD card; built-in dual MICs; 1-ch speaker; support two-way talk.
> 12 VDC/PoE power supply.
> IP67 protection.
> Sound and light alarm (red and blue lights).
> SMD 4.0.
> Supports AI SSA and one-tap arming and disarming.
> SMD area can be set in warm light areas that support triggering alarms.
Dahua Technology: A Global Leader in Video-Centric AIoT Solutions
Dahua Technology stands as a global leader in video-centric AIoT solutions and services. With a commitment to continuous innovation and excellence, the company strives to drive digital transformation worldwide. Recently, Dahua upgraded its corporate strategy from “Intelligence” to “Integrated Intelligence.” This shift aligns with its goal of enhancing both urban and enterprise operations through smarter, more integrated solutions.
Advancing Urban Business: Smart Governance and Ecological Collaboration
For urban business, Dahua is committed to transforming city management. The company is facilitating the transition from traditional urban management to more efficient urban governance. Moreover, Dahua is helping cities move toward operational autonomy and enhanced public safety with upgraded security systems. At the same time, the company is focusing on improving ecological governance, promoting collaboration in environmental monitoring to ensure sustainable urban development.
Empowering Enterprises: Comprehensive Security and Digital-Intelligent Manufacturing
Dahua is also driving change in enterprise business. The company has expanded its focus beyond optimizing security systems to developing comprehensive, integrated security solutions. This shift enables businesses to address evolving security needs while also improving production efficiency. Additionally, Dahua is empowering enterprises by enhancing their digital-intelligent manufacturing capabilities and decision-making processes, helping organizations achieve greater operational efficiency and competitiveness.
Dahua’s Mission: Enabling a Smarter Society and Better Living
Dahua’s mission is clear: “Enabling a Smarter Society and Better Living.” To achieve this, the company provides end-to-end security solutions, systems, and services that create value for cities, enterprises, and consumers. By focusing on customer success and employee achievements, Dahua consistently delivers high-quality products and services that meet the diverse needs of its clients.
Driving a Positive Impact: Contributing to a Safe, Low-Carbon World
Furthermore, Dahua is dedicated to contributing to a safer, low-carbon, and more harmonious world. The company’s core values guide every aspect of its operations, ensuring that it not only meets but exceeds customer expectations. Through its proactive service and innovative solutions, Dahua continues to make a lasting impact on global communities.
Camera
Image Sensor
1/1.8" CMOS
Max. Resolution
3840 (H) × 2160 (V)
ROM
256 MB
RAM
2 GB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100,000 s
Min. Illumination
0.0008 Lux@F1.0 (Color, 30IRE)
0.0004 Lux@F1.0 (B/W, 30IRE)
0 lux (Illuminator on)
S/N Ratio
>56 dB
Illumination Distance
Up to 50 m (164.04 ft) (IR)
Up to 50 m (164.04 ft) (Warm light)
Illuminator On/Off Control
Auto;Manual
Illuminator Number
4 (Multi-core (IR + warm) light)
Angle Adjustment
Pan: 0°–360° Tilt: 0°–90° Rotation: 0°–360°
Lens
Lens Type
Fixed-focal
Lens Mount
M16
Focal Length
2.8 mm;3.6 mm
Max. Aperture
F1.0
Field of View
2.8 mm: H: 109°; V: 59°; D: 131°
3.6 mm: H: 93; V: 50°; D: 111°
Iris Control
Fixed
Close Focus Distance
2.8 mm: 2.1 m (6.89 ft)
3.6 mm: 4.4 m (14.44 ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
2.8 mm
82.0 m
(269.03 ft)
32.8 m
(107.64 ft)
16.4 m
(53.81 ft)
8.2 m
(26.90 ft)
3.6 mm
100.0 m
(328.08 ft)
40.2 m
(131.23 ft)
20.0 m
(65.62 ft)
10.0 m
(32.81 ft)
DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.
Intelligence
IVS (Perimeter Protection)
Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)
SMD
SMD 4.0
Smart Search
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
AcuPick
Uses deep learning algorithms and works with back-end devices to accurately match targets, such as people and motor vehicles, and search through live and recorded videos to quickly locate targets.
AI SSA
Adopt deep learning algorithms to adjust the parameters
of the image to suit the conditions.
Video
Video Compression
H.265; H.264; H.264H; H.264B; MJPEG (only supported by sub stream)
Smart Codec
Smart H.265+; Smart H.264+
AI Coding
AI H.265 (Compression rate ≥25%)
AI H.264 (Compression rate ≥25%)
Video Frame Rate
Main stream: 3840 × 2160@(1 fps–25/30 fps) Sub stream: 1920 × 1080@(1 fps–25/30 fps)
Third stream: 1920 × 1080@(1 fps–25/30 fps) *The values above are the max. frame rates of each stream; for multple streams, the values will be subjected to the total encoding capacity.
